Threaded L Type 3 Way Stainless Steel Ball Valve

The Threaded L‑Port 3‑Way Stainless Steel Ball Valve is a high-performance industrial valve designed for reliable flow control in demanding environments. Featuring an L‑port configuration, this threaded stainless steel valve allows precise diversion or shut-off of media flow between two outlets using a quarter-turn handle or actuator-ready ISO 5211 top mount. Constructed from durable AISI 304 or AISI 316 stainless steel, it offers excellent corrosion resistance and mechanical strength, making it ideal for chemical, food, pharmaceutical, and process applications. Certified to international standards, with options for manual or automated operation, this valve is designed for robust performance in pressures up to PN40 and temperatures from −30°C to +180°C.

Features

• Corrosion-resistant stainless steel construction

• Efficient L‑port design for flow diversion or fluid routing

• Threaded end connections for easy installation

• ISO 5211 actuator-ready for automation

• Wide pressure and temperature operating range

• PTFE seals for chemical resistance and leak control

• Certified to multiple international standards for safety and performance

Technical Specifications

• Valve Type: 3‑way L‑port ball valve

• Connection: Threaded (BSP/NPT options)

• Body Material: AISI 304 / AISI 316 stainless steel

• Ball & Stem Material: AISI 304 / AISI 316 stainless steel

• Sealing Material: PTFE (standard)

• Pressure Rating: PN16 / PN40

• Temperature Range: −30°C to +180°C

• Actuator Mounting: ISO 5211 compatible (optional)

• Certifications: CE, TS EN 10204 3.1, ATEX, ADR, Fire Safe, ISO 9001:2015, SIL3

• Application Media: Corrosive fluids, acids/bases, food, chemical, pharmaceutical
