Industrial Duty Flushed Manifold Pumps for Low Lubricity and High Temperature Applications

Industrial Duty Flushed Manifold Pumps for Low Lubricity and High Temperature Applications

Flush Manifold Plunger Pumps are specially designed to handle challenging fluid conditions such as low lubricity liquids (e.g., deionized water) and high-temperature fluids. These pumps are engineered with additional flush ports that allow circulation of liquid between the high-pressure and low-pressure seals, thereby enhancing seal longevity and minimizing maintenance.

Flush pumps retain the core configuration of standard plunger pumps, including inlet and outlet ports, but feature an additional set of flushing ports integrated into the manifold. This design innovation makes them ideal for demanding industrial applications where seal life and equipment durability are critical.

Flush-style models from Cat Pumps are denoted by the letters “C” or “K” at the end of the model number (e.g., 781K).

Key Features:

• Flushed manifold with dedicated inlet and outlet flushing ports

• Built to handle low lubricity liquids like Deionized (DI) water

• Engineered for applications involving elevated liquid temperatures

• Standard inlet and outlet ports for high-pressure applications

• Available in Cat Pumps C and K Series models

Benefits:

• ✅ Extended Seal Life: Circulation of flushing liquid between seals significantly improves seal durability, especially when pumping DI water or other low lubricity fluids.

• ✅ Seal Cooling: Flush system helps dissipate heat, extending seal performance in high-temperature environments.

• ✅ Reduced Maintenance: Longer seal life and decreased wear on components lead to less frequent maintenance and lower operating costs.

• ✅ Ceramic Plunger Protection: Reduced thermal stress lowers the risk of cracking or pitting, enhancing plunger longevity.

Applications:

• Semiconductor manufacturing (DI water systems)

• Boiler feed or pre-treatment systems

• Laboratory or pharmaceutical processes

• High-temperature industrial cleaning systems

• Any application involving heat-sensitive or low-lubricity fluids
