Axial Nozzle Check Valves
Compact, non-slam axial nozzle check valve designed for low pressure loss, fast response, and fire-safe performance in critical industrial systems.
Surface Axial Nozzle Check Valves are advanced non-return valves engineered to prevent reverse flow and protect critical equipment in industrial process systems. Featuring a streamlined axial flow path and optimized ring/disc geometry, these valves deliver very low pressure loss, fast response, and smooth non-slam operation. Their compact design makes them ideal for space-constrained surface installations such as oil and gas platforms, LNG facilities, pump discharge lines, and antisurge systems.
Built according to major API and ISO standards, they are available in forged or cast bodies with hard-faced metal seating and fire-safe construction. They support a wide range of materials, temperature classes, pressure ratings, and end connections, with optional certifications including NACE, PED, ATEX, and high-level API QSL/PSL requirements.
Main Features
- Forged or Cast Body
- Hard Faced Metal Seated
- Non Slam Type
- Intrinsically Fire Safe
- Optimized Ring/Disc design based on process conditions
Options
- Customized size and design pressure according to Project requirements
- Available Design Validation: API 6A PR2F, ISO 15848-1, API 6D
- Client specific Type Approval or Design Validation test
- PED
- ATEX
- Painting according to Customer Specification
Benefit
- Compact design
- High Speed response time
- Low pressure loss
- Maintenance Free
Technical Data
API 6D, API 6A, ISO 14313, ISO 10423
API 6D:
2”- 60”
Class: # 150-2500
API 6A:
1 13/16” – 21 ¼”
From RWP Form 13.8 MPa (2.000PSI) to RWP 103.4 MPa (15.000PSI)
QSL 2, QSL3/3G, QSL4/4G
PSL-1, PSL-2, PSL-3, PSL-4
Main Components:
- Carbon steel
- Low temperature carbon steel
- Stainless austenitic steel and super-austenitic steel
- Stainless duplex and super-duplex
- Nickel superalloys (such as Monel, Inconel 625, Hastelloy)
NACE material available upon request
Norsok material available upon request
